Part Number or the Week S3EP-V-VAD-HPR-R

Gent Main Control Panel Stainless Steel Flush Mounting Kit

Part no.COMPACT-FLUSH-SS
BrandGent
RangeCompact Plus
Sub-rangeCompact Plus Accessories
GENT COMPACT-FLUSH-SS Stainless Steel Flush Frame — rear view showing recessed back plate with six mounting holes

Image for illustration; item supplied may differ

£497.54 ex VAT
£597.05 inc VAT
In stock
Ships in 1 to 2 working days
Dates are based on our supplier's lead times and may change.
Free UK delivery over £250 ex VAT, otherwise £9.95 ex VAT (£11.94 inc VAT).

Volume pricing

Bulk discount, applied automatically at checkout.

QuantityUnit price ex VAT
1+£497.54
5+£480.13
25+£467.69
75+£460.22

Don't forget

At a glance

  • Stainless steel surroundCOMPACT-FLUSH-SS is a stainless steel flush surround.
  • Semi-flush installationProvides semi-flush mounting for a Compact panel.
  • For COMPACT-PLUSFits the COMPACT-PLUS control panel.
  • Compact Plus node fitFits the Vigilon Compact Plus network node.
  • Older Compact panel fitFits the older COMPACT-24-N panel.
  • Required stainless steel doorRequires the stainless steel door VIG-RPT-DOOR-SS.

Documents

PDFDatasheet (COMPACT-FLUSH, COMPACT-FLUSH-SS, COMPACT-LPC-EN, COMPACT-NC) (PDF, 376 KB)
DescriptionSpecificationsDocumentsGuidesOptional accessoriesFAQsAlso in this range

Description

The Gent COMPACT-FLUSH-SS is a stainless steel flush surround for semi-flush mounting a Compact control panel. It fits COMPACT-PLUS, the Vigilon Compact Plus network node and the older COMPACT-24-N panel. The surround requires the stainless steel door VIG-RPT-DOOR-SS. It fits into a wall opening 320mm wide and 380mm high, with a depth of at least 93mm. The surround is secured to the side walls of the opening through 5mm fixing holes. The panel backbox then attaches to the surround with four 5mm screws supplied with the surround. The alternative COMPACT-FLUSH surround is supplied in black.

COMPACT-FLUSH-SS is the stainless steel flush surround for semi-flush mounting a Gent Compact panel. It fits COMPACT-PLUS, the Vigilon Compact Plus network node and the older COMPACT-24-N panel.

Read the full technical description

The wall aperture must be 320mm wide and 380mm high, with a depth of at least 93mm. These dimensions apply to the mounting opening.

The surround is secured to the aperture side walls through 5mm diameter fixing holes. The panel backbox then attaches to the surround using four 5mm screws supplied with the surround.

COMPACT-FLUSH-SS is the stainless steel surround and requires the stainless steel door VIG-RPT-DOOR-SS. COMPACT-FLUSH is supplied in black.

Specifications

ManufacturerGent
Product typeMain control panel stainless steel flush mounting kit
Surround materialStainless steel
Mounting formSemi-flush
Control panel fitCOMPACT-PLUS
Network node fitVigilon Compact Plus network node
Older panel fitCOMPACT-24-N
Required doorVIG-RPT-DOOR-SS stainless steel door
Shared surround mounting aperture320mm wide x 380mm high; depth at least 93mm
Shared surround fixing holes5mm diameter
Backbox fixing in shared arrangementFour 5mm screws supplied with the flush surround
Black surround optionCOMPACT-FLUSH

Specifications per manufacturer documentation, subject to change. E&OE.

Documents

DocumentTypeSizeDownload
Datasheet (COMPACT-FLUSH, COMPACT-FLUSH-SS, COMPACT-LPC-EN, COMPACT-NC)Datasheet376 KBDownload PDF

Guides

Optional accessories

FAQs

What is COMPACT-FLUSH-SS used for?

COMPACT-FLUSH-SS is the stainless steel flush surround for semi-flush mounting a Gent Compact panel. It fits the COMPACT-PLUS control panel, the Vigilon Compact Plus network node and the older COMPACT-24-N panel. The surround is secured into a prepared wall opening before the panel backbox is attached to it. The opening must be 320mm wide and 380mm high, with a depth of at least 93mm. Four supplied 5mm screws attach the backbox to the surround.

Which panels does COMPACT-FLUSH-SS fit?

The surround fits the COMPACT-PLUS control panel, the Vigilon Compact Plus network node and the older COMPACT-24-N panel. It provides a semi-flush mounting arrangement in which the surround is secured to the sides of a wall aperture and the panel backbox attaches to it. COMPACT-FLUSH is the black surround, while COMPACT-FLUSH-SS is the stainless steel option. The stainless steel surround requires the stainless steel door VIG-RPT-DOOR-SS. The surround and the stainless steel door have separate part numbers.

What wall opening does the surround need?

The wall opening must be 320mm wide and 380mm high, with a depth of at least 93mm. These measurements apply to the aperture for the semi-flush mounting arrangement. The surround is secured to the side walls of this opening through 5mm diameter fixing holes. Once it is secured, the panel backbox attaches to the surround with four supplied 5mm screws. This mounting arrangement applies to the black COMPACT-FLUSH surround and the stainless steel COMPACT-FLUSH-SS option.

How is the panel backbox attached?

The surround is secured into the side walls of the prepared aperture before the panel backbox is attached. The surround has 5mm diameter fixing holes, and four 5mm screws supplied with the surround attach the backbox. The wall aperture must be 320mm wide and 380mm high, with a depth of at least 93mm. This provides semi-flush mounting for the COMPACT-PLUS control panel, the Vigilon Compact Plus network node and the older COMPACT-24-N panel.

How do the black and stainless steel surrounds differ?

COMPACT-FLUSH is supplied in black. COMPACT-FLUSH-SS is the stainless steel surround and requires the stainless steel door VIG-RPT-DOOR-SS. Both surrounds provide semi-flush mounting for COMPACT-PLUS, the Vigilon Compact Plus network node and the older COMPACT-24-N panel. The mounting aperture is 320mm wide and 380mm high, with a depth of at least 93mm. Each surround attaches to the aperture side walls before the panel backbox is fitted using four 5mm screws supplied with the surround.
